AirKey blind cylinder

Blind cylinder AirKey
LOKSYS-AIRKEY-PROFILE-CYLIND-BLIND-(NI)

Art.-no. 5688200029

EAN 4099618385582

All versions

Individual price display after login
AirKey blind cylinder

Art.-no. 5688200029

Individual price display after login
Quantity
PU
x 1 pcs

Exclusively for trade customers

Register now and access more than 125,000 products

One side blind, no locking function
  • Quick and easy to install as the external knob is pre-assembled

  • No need to buy software

  • Freely rotating external knob prevents tampering

  • Suitable for outdoor use

  • Optical signals when operating the knob (red = access denied, green = access allowed, blue = NFC connection)

  • External emergency power supply possible

  • Long battery life enables up to 30,000 closing cycles

  • Boring and drilling protection

  • Fire protection: 90 minutes

  • AES 128 bit encryption

  • Blacklist function

  • Rotation damping
Notice

A computer or a Bluetooth-enabled smartphone (4.0 LE or higher), an up-to-date free app for iOS or Android and the free software are required for commissioning.


The order registration is completed exclusively via the WÜDESTO configurator.


Delivery time approx. 10 working days.



Not suitable for doors with a backset measuring less than 35 mm, metal fittings with a cylindrical cover or decorative rings on aluminium doors.

Dimensions subject to change. Subject to technical changes.

Product information

Würth Catalogue

Datasheets(X)

Safety data sheet

Certificates/ Documents

 |

 |

Application area

The AirKey cylinder is a high-quality security product for indoor and outdoor use.

Instructions

The room can only be entered from the outside if the RFID knob is unlocked using an authorised method. Access authorisations can be transferred to the cylinder using a smartphone or the coding station. Credits are required to set up locking authorisations.

Area of application

Private area, Object area

Suitable for

Grille gates, Fence gates

Emergency and danger function (lockable on both sides)

No

Control system

Smartphone, Key fob AirKey, Key card AirKey, Combination key AirKey

Data transmission type

Bluetooth technology, NFC

Number of rechargeable batteries/batteries

2 PCS

Battery designation

3V CR2 lithium

Multi frequency

13,56 MHz/2,4 GHz

Data recording

Last 1000 user

Max. number of users

999 PCS

Material of profile-cylinder

Brass

Gloss level of the profile-cylinder

Matt

Surface

Nickel plated

Gloss level

Matt

Min./max. ambient temperature

-20 to 55 °C

IP protection class

IP 65

Standards

EN 1634-1, EN 15684

EC declaration of conformity (CE)

Yes

Environmental Product Declaration

Yes
