Aluminium security escutcheon PZ

Name: Aluminium security escutcheon PZ
Brand: Würth
SKU: 0688262001

SDF-ALU-ROS-CK-12-F1/SILVER

Art.-no. 0688262001

EAN 4068362431005

All versions

Similar products

Individual price display after login

Aluminium security escutcheon PZ

Art.-no. 0688262001

Individual price display after login

Quantity

x 1 pcs

Exclusively for trade customers

Login/Register
Call customer service:

Visually appealing security rosette for numerous applications, such as house doors, apartment entrance doors, garden gates etc.

The outer escutcheon has a high-pressure die cast substructure.

The 2-point screw connection of the fitting is invisible and ensures a stable, secure hold of the rosettes.

Notice

The inner rosette can be used to mark the fixing points.

Dimensions subject to change. Subject to technical changes.

Product information

Würth Catalogue

Datasheets(X)

Certificates/ Documents


Suitable for	Apartment entrance doors
Material	Aluminium
Surface	Anodised
Colour	Silver F1
Suitable for min./max. door thickness	39-68 mm
Suitable for min./max. profile-cylinder projection	11-14 mm
DIN direction	DIN R/L
Rosette diameter (outer)	55 mm
Rosette thickness (outer)	12 mm
Hole distance	38 mm
Cam diameter	10 mm
