Concrete screw EUROFAST ® EFR

Steel zinc flake coat silver EUROFAST EFR
SCR-RAISCS-CONCRETE-(EFR-63028)-6,3X28

Art.-no. 0838161028
EAN 4052703851270

Prices for customers after login
Concrete screw EUROFAST ® EFR

Art.-no. 0838161028

Prices for customers after login
Quantity
PU
x 1000 pcs

Exclusively for trade customers

Register now and access more than 125,000 products

Concrete screw for fastening insulation and roof sheeting to concrete surfaces, case-hardened steel

For use with retaining plates, shape: D (deep), H (high), XH (XtraHigh), plastic funnel TLK

Notice
  • Concrete quality = min. C 20/25

  • Bore diameter = 5.0/5.5 mm (depending on the concrete quality)

  • Drill hole depth = fastener length + min. 10 mm

  • Anchor depth = min. 25 mm
  • ETA-06/0007 approval

  • Tested in accordance with DIN 50018 = 15 Kesternich cycles
Product information

Datasheets(X)

CAD data (available after login)

Certificates/ Documents

 |

 |

Application area

The fastener is not suitable for use on solid concrete or concrete hollow block boards

Nominal diameter (d1)

6.3 mm

Length (l1)

28 mm

Head diameter (d2)

9 mm

Head height (k1)

3 mm

Head type

Pan head

Drive type

Internal TX

Thread length (tapping screw thread) (l2)

28 mm

Material

Steel, case-hardened

Surface

Flake zinc silver

Internal drive

TX25

RoHS-compliant

Yes

Approval

ETA-06/0007
