Façade membrane STAMISOL EXTREME Color

Name: Façade membrane STAMISOL EXTREME Color
Brand: Würth
SKU: 0681001191

Façade membrane STAMISOL EXTREME Color
FCNGSHT-STAMISOL-RAL3007-26X2,5M-65SM

Art.-no. 0681001191

EAN 4053479276359

All versions

Similar products

Prices for customers after login

Façade membrane STAMISOL EXTREME Color

Art.-no. 0681001191

Prices for customers after login

Quantity

x 65 m²

Exclusively for trade customers

Login/Register
Call customer service:

Façade membrane in various colours for aesthetically pleasing sealing of perforated façades up to an open joint portion of max. 70% of the façade surface and clear joint widths of up to 10 cm.

Robust and durable

Lasting resistance to UV radiation, heat and moisture

Driving rain-proof and breathable

Mechanical resistance and surface stability in strong winds

Aesthetic improvement

Can be harmoniously combined with open façade cladding

Gives the façade more contrast and depth and offers great potential for creative design

Efficient heat insulation

Outer insulation enhances comfort and boosts the building's energy balance

Protects insulation from water and wind

Prevents condensation hazards

Notice

The design must meet the "recognised codes of practice".

Stamisol roof protection films and façade membranes must only be combined with accessory products from the Stamisol system.

Product information

Würth Catalogue

Datasheets(X)

Certificates/ Documents

Application area

Sealing jointed façades

Sealing glass façades and transparent façades

Fitted directly on the heat insulation

Design	Without self-adhesive strips
Coating weight per m²	445 g
Length of roll	26 m
Roll width	2.5 m
Area	65 m²
Number of rolls per pallet	25 PCS
Material	Polyester fleece
Min./max. temperature resistance	-40 to 100 °C
Thickness	0.8 mm
Suitable for makeshift roofing/makeshift coverage	24 Month
Ultraviolet resistance	Permanent
Colour	Aubergine coloured
Building material class/conditions	E - Normally inflammable / in accordance with DIN EN 13501
Air layer thickness equivalent to water-vapour diffusion/conditions	0.05 m / in accordance with DIN EN 12572 C
Resistance to penetration of water	W1
Resistance to tear propagation (longitudinal)	280 N
Resistance to tear propagation (transverse)	280 N
Longitudinal tensile force per 50 mm	380 N
Transverse tensile force per 50 mm	380 N

Additive article:

Product

Description

Quantity

Price
/PU

STAMCOLL AS adhesive and sealant For bonding Stamisol overlaps and connecting to roofs and façades

ADH-ROOFSHT-(STAMCOLL-AS)-310ML

Art.-no. 0893700130

For bonding Stamisol overlaps and connecting to roofs and façades

Adhesive STAMCOLL N55 For bonding Stamisol overlaps and connecting to roofs and façades

ADH-ROOFSHT-STAMCOLL-N55-1,9LTR

Art.-no. 0893700131

For bonding Stamisol overlaps and connecting to roofs and façades

x 4 pcs

Adhesive STAMCOLL N55 For bonding Stamisol overlaps and connecting to roofs and façades

ADH-ROOFSHT-TAMCOLL-N55-5,0L

Art.-no. 0893700132

For bonding Stamisol overlaps and connecting to roofs and façades

x 1 pcs
