Stainless steel security door fitting S 25

Name: Stainless steel security door fitting S 25
Brand: Würth
SKU: 0687251258

Stainless steel security door fitting S 25
SDF-A2-S25/FS-ES1-HH-CC-72-14-MATT

Art.-no. 0687251258

EAN 4065746406956

All versions

Similar products

Individual price display after login

Stainless steel security door fitting S 25

Art.-no. 0687251258

Individual price display after login

Quantity

x 1 pcs

Exclusively for trade customers

Login/Register
Call customer service:

Fire protection tested, meets the valid requirements for fire protection and escape doors

The handle and base plate are securely connected with pivoting mounting for the best possible hold

The continuous screw connection with metric screws and support cam provide optimal support for a short plate

Notice

The door handle fittings include either an unmounted square expanding pin or spindle ■ 9 mm. Door handles can also be supplied with an anti-bacterial surface by special order.

Dimensions subject to change. Subject to technical changes

Product information

Würth Catalogue

Datasheets(X)

Certificates/ Documents

Application area

For fire doors, panic doors and smoke protection doors


Suitable for	Fire protection doors, Smoke protection doors
Fire protection certified	Yes
Fitting version	Handle/handle
Shape of door handle	GE (Frankfurt type)
Punched-hole	BC
Distance (from handle to lock) (E)	72 mm
Material	Stainless steel A2, 1.4301
Gloss level	Matt
Suitable for min./max. door thickness (TS)	40-66 mm
Suitable for min./max. profile-cylinder projection	10-15 mm
Square size	9 mm
DIN direction	DIN R/L
Standards	EN 1906, DIN 18257
Environmental Product Declaration	Yes
Utilisation category	Class 4
Resistance class	ES 1
Bearing Technology	Door handle, fixed, With plastic bearing
Insertion depth	41 mm
Handle length	141 mm
Handle diameter	21 mm
Door handle mount diameter	17.8 mm
Handle height inc. rosette/ label	69 mm
Hole distance	90.5 mm
Label length (outer)	170 mm
Label length (inner)	170 mm
Label thickness (outer)	14 mm
Label thickness (inner)	8 mm
Plate width (outer)	45 mm
Plate width (inner)	45 mm

Classification key according to DIN EN 1906: 2012-12
4	7	-	B1	1	4	2	U
